Details
The Fluid HT 20.1 provides evolved fit, handling and ride quality that'll elevate every young riders' trail experience.
The Fluid HT 20.1 is the ultimate singletrack adventure hardtail. The progressive aluminum frame and fork features 2.6" mid-fat tires for added grip and passive suspension and provides next-level Trail performance for riders from 3'9" to 4'3".
Reasons It's Rad
- Engineered for real rides and unlimited potential.
- Always find the right gear with quality components.
- Stopping power with minimal effort for maximum control.
- Cable routing balances keeping tidy and maintenance.
- Created to meet the needs of evolving riders.
Wheel Size (in) | 20" |
---|---|
Stack (mm) | 410 |
Head Tube Angle (°) | 65 |
Seat Tube Length (mm) | 255 |
Effective Seat Tube Angle (°) | 73 |
Rear Centre Length (mm) | 338 |
Bottom Bracket Drop (mm) | 15 |
Bottom Bracket Height (mm) | 245 |
Horizontal Top Tube (mm) | 455 |
Wheelbase (mm) | 885 |
Head Tube Length (mm) | 110 |
Crank Length (mm) | 140 |
20" Wheel Size | Rider Height (in) | Rider Height (cm) |
---|---|---|
Growing In Period | 3'8" - 3' 9 1/2" | 111 - 114 |
Optimal Fit | 3' 9 1/2" - 4'3" | 114 - 129 |
Specs
Frame | Aluminum HT |
---|---|
Fork | Aluminum |
Rims | Aluminum Double Wall, 28H, 30mm ID, 20" |
Hubs |
Front: Aluminum, 9x100mm, 6 Bolt Rear: Aluminum 10x135mm, HG, 6 Bolt |
Spokes | Stainless, Black |
Tires | Vee Crown Gem 2.6" |
Bottom Bracket | Sealed Bearing Square Taper |
Crankset | Alloy 3 Piece , 28T Narrow Wide, 140mm |
Shifters | SunRace Trigger |
Rear Derailleur | SunRace RDM57LD |
Cassette/Freewheel | SunRace, 11-34T, 8 Speed |
Chain | KMC |
Brakes | Tektro HD-M286 Hydraulic |
Rotors | Tektro 160mm |
Brake Levers | Tektro Hydraulic 2-Finger Jr. |
Handlebars | Alloy Jr. 540mm, 45mm Rise |
Tape/Grips | Norco Youth |
Stem | Alloy, 45mm Length, 31.8mm Clamp |
Seatpost | Alloy 27.2mm |
Saddle | Norco Youth |
Pedals | Jr. MTB Flat, Black |
* Subject to change without notice.
